dual flow solenoid valve, electromagnetic valve

FOB Reference Price:Get Latest Price
US $42-48 / Sets | 50 Set/Sets high quality oil solenoid brass valve (Min. Order)
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
Zhejiang, China (Mainland)
Brand Name:
Chunhui
Model Number:
DV1050Ex(F-10)
Application:
fuel dispenser
Material:
Brass
Temperature of Media:
Medium Temperature
Pressure:
Low Pressure
Power:
Solenoid
Media:
Oil
Port Size:
Flange connection
Structure:
Diaphragm
Keyword:
high quality oil solenoid brass valve
Certificate:
Atex
current customers:
Gilbarco,Tokheim, Wayne, Tatsuno, Sinopec
Standard or Nonstandard:
Standard
Supply Ability
Supply Ability:
10000 Set/Sets per Month high quality oil solenoid brass valve
Packaging & Delivery
Packaging Details
high quality oil solenoid brass valve
carton box, wooden package.
Port
Shanghai / Ningbo, China
Lead Time :
Shipped in 15 days after payment

home>>product categories>>hot product

dual flow solenoid valve, electromagnetic valve

Brief introduction: it is used to control the high and low flow of the computerized fuel dispenser to achieve rapid fueling with high efficiency and give a precise measuring of the fueled amount, the suitable media are including petroleum, diesel, kerosene



 Main Technical Specification

      Item

Parameter

Item

Parameter

Medium

Petrol,diesel oil,kerosene etc,

Ration 5L

Preact 0.5L

Ambient Temperature

-40℃~+55℃

Displayed Value when main Valve Closed

≤4.85L

Medium Temperature

-40℃~+55℃

Voltage Input

AC230V 50HZ,





Pressure Range



0.035~0.35MPa



Voltage deviation

-10%~+15%

Relative Humidity

≤95%

Flow

DN25(1”)

>52L/min(Big Flow) 3~5L/min(Small Flow)

Insulating Strength

≥20MΩ

Lead Length

1.5m(standard)

Working Mode

100%

Power

2x5.5W

Anti-Explosion Mark

Ex mb II T3

Coil Class

H

Material of valve body and Valve Cover

Copper or Aluminum Alloy

Life cycle

Under normal working condition, the continuous cycle time is above 1000,000
